Обратный клапан с уплотнением, резьба BSP
Уточнить цену
Обратный клапан с уплотнением, резьба BSP
Если вы хотите заказать фитинг из нержавеющей стали, пожалуйста, измените первые две цифры с 50.. на 51..
Характеристики
Впускной клапан, нержавеющая сталь
| Артикул | Бренд | серия | WP (bar) | Ø трубы D1 | Ø трубы W | резьба G | L1 (мм) | L2 (мм) | CH1 | Ø pass. | резьба JIC 37° B |
| 511701.3 | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/8 | 64 | 8 | 19 | 2.8 | 7/16-20 |
| 511702.3 | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/8 | 64 | 8 | 19 | 4 | 1/2-20 |
| 511703.3 | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/4 | 64.1 | 12 | 19 | 4 | 9/16-18 |
| 511704.3 | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/8 | 73.2 | 12 | 32 | 8 | 3/4-16 |
| 511705.3 | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 1/2 | 79.3 | 14 | 41 | 11 | 7/8-14 |
| 511706.3 | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 3/4 | 90.9 | 16 | 50 | 14.5 | 11/16-12 |
| 511707.3 | CAST | UNIVERSALE | 290 | 25 | 1 | 1 | 92.1 | 18 | 50 | 18 | 15/16-12 |
| 511708.3 | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 11/4 | 111.3 | 20 | 70 | 25.5 | 15/8-12 |
| 511709.3 | CAST | UNIVERSALE | 240 | 38 | 11/2 | 11/2 | 114.5 | 22 | 70 | 29 | 17/8-12 |
Впускной клапан, углеродистая сталь
| Артикул | Бренд | серия | WP (bar) | Ø трубы D1 | Ø трубы W | резьба G | L1 (мм) | L2 (мм) | CH1 | Ø pass. | резьба JIC 37° B |
| 501701.3 | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/8 | 64 | 8 | 19 | 2.8 | 7/16-20 |
| 501702.3 | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/8 | 64 | 8 | 19 | 4 | 1/2-20 |
| 501703.3 | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/4 | 64.1 | 12 | 19 | 4 | 9/16-18 |
| 501704.3 | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/8 | 73.2 | 12 | 32 | 8 | 3/4-16 |
| 501705.3 | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 1/2 | 79.3 | 14 | 41 | 11 | 7/8-14 |
| 501706.3 | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 3/4 | 90.9 | 16 | 50 | 14.5 | 11/16-12 |
| 501707.3 | CAST | UNIVERSALE | 290 | 25 | 1 | 1 | 92.1 | 18 | 50 | 18 | 15/16-12 |
| 501708.3 | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 11/4 | 111.3 | 20 | 70 | 25.5 | 15/8-12 |
| 501709.3 | CAST | UNIVERSALE | 240 | 38 | 11/2 | 11/2 | 114.5 | 22 | 70 | 29 | 17/8-12 |
Выпускной клапан, нержавеющая сталь
| Артикул | Бренд | серия | WP (bar) | Ø трубы D1 | Ø трубы W | резьба G | L1 (мм) | L2 (мм) | CH1 | Ø pass. | резьба JIC 37° B |
| 511501.3 | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/8 | 64 | 8 | 19 | 2.8 | 7/16-20 |
| 511502.3 | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/8 | 64 | 8 | 19 | 4 | 1/2-20 |
| 511503.3 | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/4 | 64.1 | 12 | 19 | 4 | 9/16-18 |
| 511504.3 | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/8 | 73.2 | 12 | 32 | 8 | 3/4-16 |
| 511505.3 | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 1/2 | 79.3 | 14 | 41 | 11 | 7/8-14 |
| 511506.3 | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 3/4 | 90.9 | 16 | 50 | 14.5 | 11/16-12 |
| 511507.3 | CAST | UNIVERSALE | 290 | 25 | 1 | 1 | 92.1 | 18 | 50 | 18 | 15/16-12 |
| 511508.3 | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 11/4 | 111.3 | 20 | 70 | 25.5 | 15/8-12 |
| 511509.3 | CAST | UNIVERSALE | 240 | 38 | 11/2 | 11/2 | 114.5 | 22 | 70 | 29 | 17/8-12 |
Выпускной клапан, углеродистая сталь
| Артикул | Бренд | серия | WP (bar) | Ø трубы D1 | Ø трубы W | резьба G | L1 (мм) | L2 (мм) | CH1 | Ø pass. | резьба JIC 37° B |
| 501501.3 | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/8 | 64 | 8 | 19 | 2.8 | 7/16-20 |
| 501502.3 | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/8 | 64 | 8 | 19 | 4 | 1/2-20 |
| 501503.3 | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/4 | 64.1 | 12 | 19 | 4 | 9/16-18 |
| 501504.3 | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/8 | 73.2 | 12 | 32 | 8 | 3/4-16 |
| 501505.3 | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 1/2 | 79.3 | 14 | 41 | 11 | 7/8-14 |
| 501506.3 | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 3/4 | 90.9 | 16 | 50 | 14.5 | 11/16-12 |
| 501507.3 | CAST | UNIVERSALE | 290 | 25 | 1 | 1 | 92.1 | 18 | 50 | 18 | 15/16-12 |
| 501508.3 | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 11/4 | 111.3 | 20 | 70 | 25.5 | 15/8-12 |
| 501509.3 | CAST | UNIVERSALE | 240 | 38 | 11/2 | 11/2 | 114.5 | 22 | 70 | 29 | 17/8-12 |
