Фланец SAE код 61
Уточнить цену
Фланец SAE код 61
Характеристики
| Артикул | Бренд | DN | ID (дюйм) | DASH | Соед. дюйм | DASH | H | L | A | WP (bar) | WP (psi) |
| CS1212FL | TIEFFE | 19 | 3/4 | -12 | 3/4 | 12 | 55 | 106 | 38.1 | 350 | 5 000 |
| CS1216FL | TIEFFE | 19 | 3/4 | -12 | 1 | 16 | 57 | 108 | 44.5 | 350 | 5 000 |
| CS1220FL | TIEFFE | 19 | 3/4 | -12 | 1 1/4 | 20 | 55 | 106 | 50.8 | 280 | 4 000 |
| CS1612FL | TIEFFE | 25 | 1 | -16 | 3/4 | 12 | 58 | 114.5 | 38.1 | 350 | 5 000 |
| CS1616FL | TIEFFE | 25 | 1 | -16 | 1 | 16 | 58 | 114.5 | 44.5 | 350 | 5 000 |
| CS1620FL | TIEFFE | 25 | 1 | -16 | 1 1/4 | 20 | 63 | 119.5 | 50.8 | 280 | 4 000 |
| CS1624FL | TIEFFE | 25 | 1 | -16 | 1 1/2 | 24 | 55 | 115.5 | 60.4 | 210 | 3 000 |
| CS2016FL | TIEFFE | 31.5 | 1.1/4 | -20 | 1 | 16 | 64 | 130.5 | 44.5 | 350 | 5 000 |
| CS2020FL | TIEFFE | 31.5 | 1.1/4 | -20 | 1 1/4 | 20 | 64 | 130.5 | 50.8 | 280 | 4 000 |
| CS2024FL | TIEFFE | 31.5 | 1.1/4 | -20 | 1 1/2 | 24 | 68 | 134.5 | 60.4 | 210 | 3 000 |
| CS2032FL | TIEFFE | 31.5 | 1.1/4 | -20 | 2 | 32 | 75 | 141.5 | 71.4 | 210 | 3 000 |
| CS2424FL | TIEFFE | 38 | 1.1/2 | -24 | 1 1/2 | 24 | 73 | 155.5 | 60.4 | 210 | 3 000 |
| CS2432FL | TIEFFE | 38 | 1.1/2 | -24 | 2 | 32 | 76 | 158.5 | 71.4 | 210 | 3 000 |
| CS3232FL | TIEFFE | 51 | 2 | -32 | 2 | 32 | 77 | 176.5 | 71.4 | 210 | 3 000 |
| CS3240FL | TIEFFE | 51 | 2 | -32 | 2 1/2 | 40 | 90 | 186.5 | 84.1 | 175 | 2 500 |
