Угловые 45° NPTF уплотнение тип C
Уточнить цену
Угловые 45° NPTF уплотнение тип C
Если Вы хотите заказать изделие из нержавеющей стали, замените первые две цифры артикула с 20.... на 21....
Позиция доступна только в плановых заказах.
Позиция доступна только в плановых заказах.
Характеристики
Изделия из нержавеющей стали
| Артикул | Класс | Бренд | серия | WP (bar) | Ø трубы D1 | Ø трубы W | резьба P | L1 (мм) | L2 (мм) | L3 | CH1 | резьба JIC 37° A |
| 211301.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/8 | 19.5 | 16.5 | 10 | 11 | 7/16-20 |
| 211302.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/8 | 20 | 16.5 | 10 | 14 | 1/2-20 |
| 211303.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/4 | 21.5 | 22 | 14.5 | 14 | 9/16-18 |
| 211304.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/8 | 25.5 | 24 | 14.5 | 19 | 3/4-16 |
| 211305.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 1/2 | 29 | 29.5 | 19 | 22 | 7/8-14 |
| 211306.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 3/4 | 33 | 30.5 | 19 | 27 | 11/16-12 |
| 211307.3 | PROFESSIONAL | CAST | UNIVERSALE | 290 | 25 | 1 | 1 | 38 | 38 | 24 | 33 | 15/16-12 |
| 211308.3 | PROFESSIONAL | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 11/4 | 40 | 42 | 25 | 41 | 15/8-12 |
| 211309.3 | PROFESSIONAL | CAST | UNIVERSALE | 240 | 38 | 11/2 | 11/2 | 46 | 45 | 26 | 48 | 17/8-12 |
| 211310.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/4 | 20 | 22 | 14.5 | 14 | 7/16-20 |
| 211311.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/4 | 20 | 22 | 14.5 | 14 | 1/2-20 |
| 211312.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/8 | 21.5 | 16.5 | 10 | 14 | 9/16-18 |
| 211313.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 3/8 | 23 | 24 | 14.5 | 19 | 9/16-18 |
| 211314.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/2 | 23.5 | 29.5 | 19 | 22 | 9/16-18 |
| 211315.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 1/4 | 25.5 | 24 | 14.5 | 19 | 3/4-16 |
| 211316.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 1/2 | 26 | 29.5 | 19 | 22 | 3/4-16 |
| 211317.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/4 | 27 | 30.5 | 19 | 27 | 3/4-16 |
| 211318.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 3/8 | 29 | 25.5 | 14.5 | 22 | 7/8-14 |
| 211319.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 3/4 | 30 | 30.5 | 19 | 27 | 7/8-14 |
| 211320.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 1/2 | 33 | 30.5 | 19 | 27 | 11/16-12 |
| 211321.3 | PROFESSIONAL | CAST | UNIVERSALE | 290 | 18-20 | 3/4 | 1 | 37 | 38 | 24 | 33 | 11/16-12 |
| 211322.3 | PROFESSIONAL | CAST | UNIVERSALE | 290 | 25 | 1 | 3/4 | 38 | 33 | 19 | 33 | 15/16-12 |
| 211323.3 | PROFESSIONAL | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 1 | 40 | 41 | 24 | 41 | 15/8-12 |
Изделия из углеродистой стали
| Артикул | Класс | Бренд | серия | WP (bar) | Ø трубы D1 | Ø трубы W | резьба P | L1 (мм) | L2 (мм) | L3 | CH1 | резьба JIC 37° A |
| 201301.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/8 | 19.5 | 16.5 | 10 | 11 | 7/16-20 |
| 201302.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/8 | 20 | 16.5 | 10 | 14 | 1/2-20 |
| 201303.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/4 | 21.5 | 22 | 14.5 | 14 | 9/16-18 |
| 201304.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/8 | 25.5 | 24 | 14.5 | 19 | 3/4-16 |
| 201305.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 1/2 | 29 | 29.5 | 19 | 22 | 7/8-14 |
| 201306.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 3/4 | 33 | 30.5 | 19 | 27 | 11/16-12 |
| 201307.3 | PROFESSIONAL | CAST | UNIVERSALE | 290 | 25 | 1 | 1 | 38 | 38 | 24 | 33 | 15/16-12 |
| 201308.3 | PROFESSIONAL | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 11/4 | 40 | 42 | 25 | 41 | 15/8-12 |
| 201309.3 | PROFESSIONAL | CAST | UNIVERSALE | 240 | 38 | 11/2 | 11/2 | 46 | 45 | 26 | 48 | 17/8-12 |
| 201310.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 6 | 1/4 | 1/4 | 20 | 22 | 14.5 | 14 | 7/16-20 |
| 201311.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 8 | 5/16 | 1/4 | 20 | 22 | 14.5 | 14 | 1/2-20 |
| 201312.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/8 | 21.5 | 16.5 | 10 | 14 | 9/16-18 |
| 201313.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 3/8 | 23 | 24 | 14.5 | 19 | 9/16-18 |
| 201314.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 10 | 3/8 | 1/2 | 23.5 | 29.5 | 19 | 22 | 9/16-18 |
| 201315.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 1/4 | 25.5 | 24 | 14.5 | 19 | 3/4-16 |
| 201316.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 1/2 | 26 | 29.5 | 19 | 22 | 3/4-16 |
| 201317.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 12 | 1/2 | 3/4 | 27 | 30.5 | 19 | 27 | 3/4-16 |
| 201318.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 3/8 | 29 | 25.5 | 14.5 | 22 | 7/8-14 |
| 201319.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 14-15-16 | 5/8 | 3/4 | 30 | 30.5 | 19 | 27 | 7/8-14 |
| 201320.3 | PROFESSIONAL | CAST | UNIVERSALE | 350 | 18-20 | 3/4 | 1/2 | 33 | 30.5 | 19 | 27 | 11/16-12 |
| 201321.3 | PROFESSIONAL | CAST | UNIVERSALE | 290 | 18-20 | 3/4 | 1 | 37 | 38 | 24 | 33 | 11/16-12 |
| 201322.3 | PROFESSIONAL | CAST | UNIVERSALE | 290 | 25 | 1 | 3/4 | 38 | 33 | 19 | 33 | 15/16-12 |
| 201323.3 | PROFESSIONAL | CAST | UNIVERSALE | 240 | 30-32 | 11/4 | 1 | 40 | 41 | 24 | 41 | 15/8-12 |
